Product Description
High Speed: The D6-320 hard drive enclosure adopts USB 3.2 Gen2 protocol for high-speed data transmission up to 10Gbps. With 6 hard drives installed, the read/write speed can reach up to 1,030MB/s (SATA III HDD 8TB x 6). With one hard disk installed, the read speed can reach 510MB/s (SATA III HDD 1TB SSD x 1).
Super-large Storage Space: The D6-320 HDD enclosure supports up to six 3.5"/2.5" SATA HDDs or 2.5" SATA SSDs, with a maximum single-drive capacity of 32TB for a total storage potential of 192TB. Note: The enclosure operates in standalone disk mode and does not support RAID arrays.
Plug and Play, Highly Compatible: The D6-320 DAS storage is a driver-free, plug-and-play device that offers broad compatibility with macOS, Windows, and Linux operating systems. It features a USB Type-C interface (includes a Type-C to Type-C cable) and supports a wide range of host interfaces, including USB 3.0, 3.1, 3.2, as well as Thunderbolt 3 and Thunderbolt 4.
Better Heat Dissipation: The D6-320 features an intelligent, temperature-controlled fan that automatically adjusts its speed based on HDD temperature. This low-noise design ensures optimal operating conditions and enhanced heat dissipation for your drives.
Expansion of NAS Storage Space: The D6-320 DAS storage can be connected via USB to compatible TerraMaster NAS devices. Using TerraMaster TOS (version 5.1 or later), you can create arrays and storage pools on the D6-320 to directly expand your NAS storage capacity.
Specification
D6 320 Specification
Storage
Disk Slot Number 6
Compatible Disk Types 3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
File System NTFS, APFS, Mac OS,FAT32,EXT4,exFAT
Maximum Internal Raw Capacity 192 TB (32 TB drive x 6) (Capacity will vary along with the RAID type)
RAIDs Supported SINGLE DISK
Hardware RAID /
RAID Manager Software /
RAID Manager Software Language /
RAID Online Expansion /
RAID Migration /
RAID Auto-rebuilding /
Drive Hot Swap √
HDD Sleep √
HDD S.M.A.R.T. Inspection /
Sector Inspection and Parity Check /
SSC Cache /
Daisy Chain /
HDD NCQ Technology /
Alert Notice /
Event Log /
External Ports
USB USB3.2 Type-C gen2 10Gbps
Thunderbolt /
DP Interface /
Network Interface /
USB HOST Interface /
Power Socket DC IN 12V
Reading/writing Speed (max.)
Reading Speed (max.) Read：520MB/s ( SSD* 1 ); Read：1016MB/s ( SSD* 6 )；
Writing Speed (max.) Write：500MB/s ( SSD*1 ); Write：986MB/s ( SSD*6 )；
Appearance
Size (H*W*D) 226 x 130 x 218 mm
Packaging Size (H*W*D) 312 x 189 x 267 mm
Weight net weight: 3.4 Kg Gross Weight: 4.5 Kg
Others
System fan 80 mm x 80 mm x25mm (x 2)
Fan mode Smart
Noise Level 22.3dB(A)
Power Supply
Power Supply 120 W
AC Input Voltage 100V to 240V AC
Current Frequency 50/60 HZ, Single Phase
Power Consumption 42 W(Access)
Environment Temperature
Working Temperature 0°C ~ 40°C (32°F ~ 104°F)
Storage Temperature -20°C ~ 60°C (-5°F ~ 140°F)
Relative Humidity 5% ~ 95% RH
Supported OS Windows OS、Mac OS、Linux
Warranty 2 years
Certificate CE, FCC, CCC, KC
Environment RoHS compliance
Package Contents: Host unit (x1)
Power cord (x1)
USB Cable C to Type-C (10Gb) (0.8mx1)；USB Cable A to Type-C (10Gb) (0.8mx1)
Quick Installation Guide (x1)
Power adapter (x1)
Screws (several)
Limited Warranty Note x 1
