Product Description
Massive 288TB Storage Expansion: Supports up to nine 3.5"/2.5" SATA HDDs/SSDs, with a maximum single-drive capacity of 32TB, providing up to 288TB of total storage space. Ideal for media libraries, enterprise backup, and cold data archiving.
10Gbps High-Speed Multi-Drive Performance: Utilizing the USB 3.2 Gen2 protocol, it delivers 10Gbps of bandwidth. Achieves read/write speeds up to 1016MB/s with multiple drives, significantly accelerating the transfer and processing of large files and multi-tasking workflows.
Daisy-Chaining & Broad Compatibility: Features a high-speed USB Host port on the rear for daisy-chaining additional storage devices. Compatible with 8 major operating systems including Windows, macOS, and Linux, and comes with both USB-C and USB-A cables for easy connectivity.
Independent Drive Power Management & Sleep: Equipped with 9 individual drive power switches and a master switch, allowing unused drives to be powered down independently to save energy and extend lifespan. Supports intelligent sleep mode that syncs with your computer's state.
Intelligent Cooling & All-Metal Chassis: Features a second-generation intelligent temperature-controlled fan with 4 sensors for optimal drive temperature management. The sturdy unibody metal construction ensures efficient heat dissipation and long-term durability.
Specification
D9-320 Specification
Storage
Disk Slot Number 9
Compatible Disk Types 3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
File System NTFS, APFS, Mac OS,FAT32,EXT4,exFAT
Maximum Internal Raw Capacity 288TB (32TB HDD * 9)
RAIDs Supported SINGLE DISK
HDD Sleep √
USB USB3.2 Type-C gen2 10Gbps
USB HOST Interface √
Power Socket 100V - 240V AC
Reading/writing Speed (max.)
Reading Speed (max.) Read：560MB/s ( SSD* 1 ); Read：1016MB/s ( SSD* 4)；
Writing Speed (max.) Write：520MB/s ( SSD*1 ); Write：960MB/s ( SSD*4 )；
Appearance
Size (H*W*D) 295 x 135 x 334 mm
Packaging Size (H*W*D) 370 x 235 x 437 mm
Weight net weight: 6.5 Kg Gross Weight: 8.4 Kg
Others
System fan 92 x 92 x 25 mm 3PCS
Fan mode Smart
Noise Level 22.5 dB(A)
Power Supply
Power Supply 250 W
AC Input Voltage 100V to 240V AC
Current Frequency 50/60 HZ, Single Phase
Power Consumption 100 W (4 x 22TB Seagate 22TB ST22000NM001E hard drives in read/write state)
31 W (4 x 22TB Seagate 22TB ST22000NM001E hard drives in hibernation)
Environment Temperature
Working Temperature 0°C ~ 40°C (32°F ~ 104°F)
Storage Temperature -20°C ~ 60°C (-5°F ~ 140°F)
Relative Humidity 5% ~ 95% RH
Supported OS Windows OS、Mac OS、Linux
Warranty 2 years
Certificate CE, FCC, CCC, KC
Environment RoHS compliance
Package Contents: Host unit (x1)
Power cord (x1)
USB Cable C to C(10Gb) (0.8m x1); USB Cable A to C(10Gb) (0.8m x1)
Quick Installation Guide (x1)
Power adapter (x1)
Screws (several)
Limited Warranty Note x 1
